All kinds of transfer ball bearings

Introduction

Ball transfer units

1)are omni-directional load-bearing spherical balls mounted inside a restraining fixture. They are identical in principle to a ball computer mouse upside-down, or a trackball, except there is an array of them side-by-side.

2)Typically the design involves a single large ball supported by smaller ball bearings.They are commonly used in an inverted ball up position where objects are quickly moved across an array of units, known as a ball transfer table, a type of conveyor system. This permits manual transfer to and from machines and between different sections of another conveyor system.

3)They are used in airports for luggage delivery, or in industry as part of manufacturing systems. Prior to the invention of the ball transfer unit, first patented by Autoset Production Ltd in 1958, these applications were solved by the use of inverted casters.However, casters recognize a trail, meaning that the wheels had to align before directional change could be achieved.Ball transfer units can also be used non-inverted ball down position as a type of caster, however this use is restricted by load-bearing limitations and the type of floor.

4)Manufacturers have addressed this problem with ball transfer units incorporating re-circulating ball principles, however the inverted position is still the most common application and the least problematic.

List of CY series-light & medium duty

How to choose a ball transfer unit?

• Maximum Loading Capacity = (weight of article)/3 or 9

• Maximum Spacing = (article width)/3.5; (article length)/3.5

How to arranging and installing ball transfer units?

• There are different arranging ways to fit for different moving requirements:

• There are different models of BTU fo choosing:

Applications

• Typical application in production lines:

• Typical application in goods handling:

Ball transfer units table in Dubai International Airport

Ball transfer units table in Dubai International Airport

How to delivery?

• Gross weight lower than 50kgs, we suggest delivery by courier like DHL, TNT or others
• Gross weight between 50kgs and 120kgs, we suggest delivery by aircargo
• Gross weight over 120kgs, it can be delivered by sea shipping

  General introduction of us




  We are a professional manufactuer on various kind of bearings in China for over 14 years already.

  With updated machinery and skilled staffs we have supplied stable high quality products to customers all over the world.

  Our experianced engineers and exporting team can answer your inquiry or comment at the first time,and providing professional service from factory visiting, making orders to deliver goods.




  RIght now, we have over 100 skilled staff and different kinds of machines including automatic production lines,later machine,milling machine,CNC machine etc.






  This picture showing our staff structure and basic machines list






  This picture showing updated sintering machine and skilled workers in production







  Our workshops are welcome you visiting:






  This is our workshops buliding






  We are using full new high quality raw materials only.



  This is the bronze powder-steel backing sintereing line



  This is a full automatic chamfering machine








  Detail packing steps:




  1.Clean bearings in anti-rust oil
  2.Plastic films packing bearings to rollers
  3.Bearings rollers put into plastic bag
  4.Cartons with goods information label
  5.Pallet for every 12ctns/24ctns/36ctns




  Our packings are suitable for FCL or LCL sea shipping.






  MOQ:1pc or 100pcs or 1000pcs(Different model and size have different requirement)

  Delivery: you can choose different delivery ways for different qty orders.




  Our quality management:






  We will make inter inspection on every step of production.

  Also you can order inspection company monitoring our production in our workshops.






  1.ISO/TS 16949 Production Quality Management Certification

  2.We will make measure guages calibration every 6 months

  3.Record of calibration in certified lab

  4.Certificate of lab
